Percival Scientific SciBrite LED Arabidopsis Chamber Model AR-36L3
Precision Low-Light Plant Growth with Specialized Tissue Culture Airflow
The Percival Scientific AR-36L3 is a versatile, research-grade Arabidopsis growth chamber designed for low-light plant cultivation and plant tissue culture applications within a single platform. Engineered with a specialized vertical airflow delivery system, this chamber supports traditional potted plants as well as tissue culture plates, dishes, and flasks—making it an ideal dual-use solution for modern plant science laboratories.
With consistent environmental control, plant-optimized LED lighting, and insulated shelf-level airflow, the AR-36L3 delivers reproducible conditions critical for both whole-plant physiology and in-vitro research.
Features
Dual-Use Airflow Design
A specialized rear-duct and fixed diffuser system delivers gentle, vertical airflow through each shelf, insulating experiments from heat generated by underlying light fixtures—ideal for tissue culture plates, flasks, and sensitive plant material.
Low-Light Optimized LED Illumination
SciWhite™ LEDs enhanced with red spectrum tiles provide uniform light delivery up to 350 µmol m²/s at 6″, optimized for Arabidopsis, tobacco, and other low-light species.
Advanced IntellusUltra™ Control Platform
The IntellusUltra™ Controller enables precise scheduling of temperature, lighting, humidity, and optional CO₂ control with graphical feedback and alarm logging.
Built-In Experiment Protection
Independent high and low temperature safety limits with audible and visual alarms protect valuable research material and automatically reset when conditions stabilize.
Core Technical Highlights
Environmental & Lighting
-
Lighting System:
SciWhite™ LED arrays with enhanced red spectrum
Up to 350 µmol m²/s at 6″, dimmable 10–100% in 1% increments -
Lighting Control:
Fully programmable through the IntellusUltra™ Controller
Capacity & Interior
-
Interior Volume: 29.7 cu ft
-
Work Area: 16.2 sq ft across three shelves
-
Shelving:
-
Three tiers of white epoxy-coated steel wire shelving
-
Shelf size: 27″ D × 28.8″ W
-
Shelves slide on stainless steel rail assemblies at lower elevation
-
Vertically adjustable in ½″ increments when not on rails
-
Maximum growing height: 13.5″ per tier
-
Airflow & Circulation
-
Rear wall duct delivers conditioned air to fixed diffusers at the base of each shelf
-
Air is delivered vertically upward at low velocity, minimizing desiccation and turbulence
-
Shelf-level diffuser design insulates experiments from radiant heat generated by lower lighting tiers
-
Optimized for plant tissue culture plates, dishes, and flasks, as well as whole plants
Construction & Serviceability
-
Interior:
-
24-gauge #304-4 stainless steel floor with drain and hose assembly
-
-
Exterior:
-
26-gauge smooth galvanized white side walls and top
-
Reinforced with 24-gauge backer plates
-
NSF-compliant seam design
-
-
Insulation:
-
2″ thick woodless, foamed-in-place non-CFC urethane insulation
-
93% closed cell
-
R-value: 12.5 | K-value: 0.16 | Density: 2.2 lb/cu ft
-
-
Refrigeration:
-
Self-contained air-cooled condensing unit
-
Hot gas bypass for continuous compressor operation and tight temperature control
-
Ceiling-mounted evaporator coil with twin circulation fans
-
Heat rejection: ~5200 BTU/hr (standard configuration)
-
-
Mobility:
-
Heavy-duty casters with adjustable leveling legs for lab stability
-
Access & Usability
-
Full-height access door: 29.2″ W × 57.5″ H
-
Magnetic door gasket ensures tight environmental seal
-
One airtight 1.25″ access port on right-hand wall
-
High-reflectance, environmentally friendly white powder-coated interior and exterior for maximum light utilization
Typical Applications
-
Arabidopsis thaliana growth and phenotyping
-
Tobacco and other low-light plant species
-
Plant tissue culture on plates, dishes, or in flasks
-
In-vitro propagation and early-stage development
-
Dual-use plant physiology and tissue culture laboratories
The AR-36L3 offers a rare combination of whole-plant growth capability and tissue culture-optimized airflow, making it a flexible, space-efficient solution for laboratories conducting diverse plant research under controlled conditions.
Optional Upgrades
-
Additive humidity control with sensor
-
Dehumidification system with sensor
-
CO₂ enrichment package
-
IntellusUltra™ Connect for remote monitoring
-
Android-based touchscreen interface
-
Self-contained water-cooled condensing unit
-
Dry alarm contacts
-
Dimmable or alternate LED lighting packages
Contact us for custom configurations to match your research workflow.
